Product Description
The iRb10UVN36KM-1 is a high-precision VIS-NIR line scan hyperspectral camera covering the 400–1000nm spectral range, designed for advanced spectral imaging and material analysis.
With high-resolution line scan technology, it delivers accurate spectral data for industrial inspection, scientific research, and laboratory applications.
Its superior spectral resolution makes it ideal for applications requiring detailed material identification and non-destructive analysis across multiple industries.
Key Features
- 400–1000nm VIS-NIR spectral range
- High-precision line scan hyperspectral imaging
- Excellent spectral resolution and stability
- Designed for industrial, scientific, and research use
- Supports advanced material classification and analysis
Applications
Ideal for:
- Industrial inspection systems
- Agricultural monitoring and analysis
- Pharmaceutical quality control
- Biomedical and life science research
- Material identification and sorting
Main Specifications
| Model |
iRb10UVN36KM-1
|
|
Scan Type
|
Line Scan
|
|
Spectroscopic method
|
Grating
|
|
Spectral region
|
400-1000nm
|
|
Spectral band
|
1200
|
|
Spectral FWHM
|
2.5nm
|
|
Slit width
|
25μm
|
|
Transmission efficiency
|
＞ 60%
|
|
Stray light
|
＜ 0.5%
|
|
Spatial pixel number
|
1920
|
|
Pixel size
|
5.86μm
|
|
Imaging speed
|
Full band 41Hz
390Hz can be achieved after ROI
|
|
Detector
|
CMOS
|
|
SNR(Peak)
|
600/1
|
|
Interface
|
USB3.0
|
|
Interface Lens
|
C-Mount
|
|
ROI
|
Single area
|
|
Dimension
|
22.8 x 7 x 8.6 cm (1250g)
|
|
Power dissipation
|
5W
|
Hyperspectral Camera Collection Download
